Key Specifications and Ratings
2410 (6125 metric)Time lagAC/DC ratings
Voltage Rating125VAC 125VDC
Current Rating200mA to 5A
Interrupt Rating100A AC 100A DC
Features and Application
  • Time lag, this 6.1mm x 2.6mm (also known as a 6125 SMD package) fuse withstands high inrush currents and prevents nuisance tripping, opening only when the overcurrent sustains in a circuit.
  • Intended for higher current requirements, this SMD fuse packs a lot of power in a small package and can be considered for all new designs.
  • Designed for automated assembly in printed circuit boards (PCBs), coming exclusively on tape and reel, with the reel having 1,000 pieces.
Dimensions and 3D view
Dimensions
Length0.24
Height0.1
Width0.1
UnitInch
Custom solutions
Dimensions and 3D view
Custom solutions
Dimensions
Length0.24
Height0.1
Width0.1
UnitInch
