Key Specifications and Ratings
Snapped together for multi positionInterchangeable with 6.3 x 32 mm versionUL recognized to use with supplementary fusesRetail Pack Quantity: 1PC
Voltage Rating250VAC
Current Rating8A
Features and Application
- Single pole sectional fuse block for 5 x 20mm fuses that allows as many positions to be snapped together as needed, whether it be two positions or 100 positions, with only one part number in inventory.
- Can be snapped together with the correlating 6.3 x 32mm fuse block version, allowing for the combining of both standard and metric type fuses in the same fuse block assembly.
- UL recognized to use with special-purpose and supplementary cartridge fuses, and intended for installation in end-use equipment or products.
- NEW: Select products are available in attractive retail packaging including blister & clamshell packs and convenient multi amperage assortment packs.
UL File
Dimensions and 3D view
Dimensions
Length1.56
Height0.43
Width0.55
UnitInch
Custom solutions
Dimensions and 3D view
Custom solutions
Dimensions
Length1.56
Height0.43
Width0.55
UnitInch
