Key Specifications and Ratings
Push to ResetSupplementary circuit protectionAC/DC ratings
Voltage Rating250VAC 32VDC
Current Rating1A to 20A
Interrupt Rating1000A AC 1000A DC
Features and Application
- Designed for supplementary circuit protection where branch circuit protection exists or is not required, this circuit breaker provides overload protection only and must be used with an upstream fuse that provides short circuit protection.
- Commonly used for applications where the product is plugged into utility power or has high current AC or DC requirements, such as industrial equipment, motor homes, and marine applications.
- Manually resettable, it comes with a rocker style actuator.
UL File
Dimensions and 3D view
Dimensions
Length0.74
Height1.56
Width0.74
UnitInch
Custom solutions
Dimensions and 3D view
Custom solutions
Dimensions
Length0.74
Height1.56
Width0.74
UnitInch
