Key Specifications and Ratings
Manual resetSurface mount with 1/4" studsMarine rated
Voltage Rating48VDC
Current Rating25A to 250A
Interrupt Rating 3000A DC
Features and Application
- Heavy duty and high amperage to defend accessory and auxiliary high amp draw applications in RVs, marine craft, emergency vehicles and heavy-duty trucks. With elongated body for heavy-duty lugs.
- Commonly installed alongside a vehicle's battery as the primary source of power protection. The 3,000A Interrupt Rating meets ABYC requirements for DC main circuit protection on battery banks up to 1,100 CCA capacity.
- Waterproof and ignition rated for use in marine engine compartments, meeting thorough SAE J553 and ABYC standards.
Dimensions and 3D view
Dimensions
Length3.39
Height1.71
Width1.91
UnitInch
Custom solutions
Dimensions and 3D view
Custom solutions
Dimensions
Length3.39
Height1.71
Width1.91
UnitInch
