Key Specifications and Ratings
Automatic resetSurface mount with 1/4" studsMarine ratedRetail Pack Quantity: 1PC
Voltage Rating42VDC
Current Rating25A to 200A
Interrupt Rating 3000A DC
Features and Application
- Heavy duty and high amperage to defend accessory and auxiliary high amp draw applications in RVs, marine craft, emergency vehicles and heavy-duty trucks.
- Commonly installed alongside a vehicle's battery as the primary source of power protection. The 3,000A Interrupt Rating meets ABYC requirements for DC main circuit protection on battery banks up to 1,100 CCA capacity.
- Waterproof and ignition rated for use in marine engine compartments, meeting thorough SAE J553 standards.
- NEW: Select products are available in attractive retail packaging including blister & clamshell packs and convenient multi amperage assortment packs.
Dimensions and 3D view
Dimensions
Length2.91
Height1.06
Width1.91
UnitInch
Custom solutions
Dimensions and 3D view
Custom solutions
Dimensions
Length2.91
Height1.06
Width1.91
UnitInch
